General Specifications
- Part Number: CTX9990
- Manufacturer: Parker Autoclave Engineers
- Product Type: Medium Pressure Tee Fitting
- Connection Type: Cone and Thread (SF Series)
- Maximum Working Pressure: 20,000 psi (1,379 bar)
Dimensional Data
- Outside Diameter (O.D.) Tubing Size: 9/16 inch (14.29 mm)
- Minimum Orifice / Opening: 0.359 inch (9.12 mm)
- Connection Code: SF562CX (All three ports)
Material & Temperature Ratings
- Body Material: Cold-worked 316 Stainless Steel
- Operating Temperature Range: -423°F to 1,200°F (-253°C to 649°C)
Component Inclusion
- Standard Package: Includes 1x Tee body, 3x Glands (nuts), and 3x Collars (sleeves).
