TECHNICAL SPECIFICATION SHEET
- GENERAL INFORMATION
- Brand: Parker Autoclave Engineers
- Part Number: 15BAFM12MJ12
- Component Type: High-Pressure Bulkhead Adapter Fitting
- Application: Fluid and gas handling systems requiring bulkhead mounting and connection conversion.
- PRESSURE & TEMPERATURE RATINGS
- Maximum Operating Pressure: 15,000 psi (1,034 bar)
- Pressure Class: Medium Pressure (MP) series
- Temperature Limits: Dependent on material selection (standard stainless steel rated from -423°F to 1200°F / -252°C to 649°C, subject to pressure derating at high temperatures).
- CONNECTION SPECIFICATIONS
- Connection 1 (Inlet/Outlet): 3/4" Female Medium Pressure (Autoclave SF750CX design)
- Connection 2 (Inlet/Outlet): 3/4" Male JIC (37° Flare connection)
- Configuration: Straight bulkhead adapter for partition panel mounting.
- MECHANICAL & INSTALLATION DATA
- Mounting Hole Diameter: 1.69 inches (42.92 mm)
- Included Accessories: Complete with gland nut and collar for the Medium Pressure connection side.
- Standard Material: 316 Stainless Steel (high corrosion resistance and strength).
